I mentioned in an earlier post that I had written my own ranker and thought I'd revisit this with some code.I verify and ensure the safety of microprocessors for my day job. One way that very complex CPU's are tested is to create another model of the chip which can be used to generate pseudo-random instruction streams to run on CPU. The so-called ISG can create thousands (millions!) of these tests in very little time, and the ISG is written in such a way that it can be 'tweaked' to give some control or steering to what the instruction streams will exercise on the CPU.Now simulating these instruction streams and gathering information on just what parts of the CPU are exercised, called covered, by each individual test takes time, and multiple ISG generated tests may cover the same regions of the CPU. To increase the overall coverage of of the CPU we run what is called a regression - all the tests are run and their coverage and the time they take to simulate are stored. at the end of the regression run you may have several thousands of tests that cover only part of the CPU.If you take the regression results and rank them you can find that subset of the tests that give all the coverage. Usually thousands of pseudo-random tests might be ranked and generate a sub-list of only hundreds of tests that when run would give the same coverage. What we then usually do is look at what isn't covered and generate some more tests by the ISG or other methods to try and fill the gaps; run the new regression and rank again in a loop to fully exercise the CPU and hit some target coverage goal.Ranking tests is an important part of the regression flow described above, and when it works well you forget about it. Unfortunately sometimes I want to to rank other data, for which the stock ranking program from the CAD tool vendors does not fit. So here is the guts of a ranking program that will scale to handling hundreds of thousands of tests and coverage points.InputNormally I have to parse my input from text or HTML files of results generated by other CAD programs - it is tedious work that I will skip by providing idealised inputs in the form of a Python dict. (Sometimes the code for parsing input files can be as large or larger than the ranking algorithm).Let us assume that each ISG test has a name, runs for a certain 'time' and when simulated is shown to 'cover' a set of numbered features of the design. after the parsing, the gathered input data is represented by the results dict in the program. 1 2 results = { 3 # 'TEST': ( TIME, set([COVERED_POINT ...])), 4 'test_00': ( 2.08, set([2, 3, 5, 11, 12, 16, 19, 23, 25, 26, 29, 36, 38, 40])), 5 'test_01': ( 58.04, set([0, 10, 13, 15, 17, 19, 20, 22, 27, 30, 31, 33, 34])), 6 'test_02': ( 34.82, set([3, 4, 6, 12, 15, 21, 23, 25, 26, 33, 34, 40])), 7 'test_03': ( 32.74, set([4, 5, 10, 16, 21, 22, 26, 39])), 8 'test_04': (100.00, set([0, 1, 4, 6, 7, 8, 9, 11, 12, 18, 26, 27, 31, 36])), 9 'test_05': ( 4.46, set([1, 2, 6, 11, 14, 16, 17, 21, 22, 23, 30, 31])), 10 'test_06': ( 69.57, set([10, 11, 15, 17, 19, 22, 26, 27, 30, 32, 38])), 11 'test_07': ( 85.71, set([0, 2, 4, 5, 9, 10, 14, 17, 24, 34, 36, 39])), 12 'test_08': ( 5.73, set([0, 3, 8, 9, 13, 19, 23, 25, 28, 36, 38])), 13 'test_09': ( 15.55, set([7, 15, 17, 25, 26, 30, 31, 33, 36, 38, 39])), 14 'test_10': ( 12.05, set([0, 4, 13, 14, 15, 24, 31, 35, 39])), 15 'test_11': ( 52.23, set([0, 3, 6, 10, 11, 13, 23, 34, 40])), 16 'test_12': ( 26.79, set([0, 1, 4, 5, 7, 8, 10, 12, 13, 31, 32, 40])), 17 'test_13': ( 16.07, set([2, 6, 9, 11, 13, 15, 17, 18, 34])), 18 'test_14': ( 40.62, set([1, 2, 8, 15, 16, 19, 22, 26, 29, 31, 33, 34, 38])), 19 } 20 Greedy ranking algorithmThe object of the algorithm is to select and order a subset of the tests that:Cover as many of the coverage points as possible by at least one test.After the above, reduce the number of tests needed to achieve that maximum coverage by as much as is pos
